By Melanie Lefkowitz, Staff Writer, Cornell Chronicle
Cornell researchers have invented an earphone that can continuously track full facial expressions by observing the contour of the cheeks—and can then translate expressions into emojis or silent speech commands, according to an article on the Cornell Chronicle website.
With the ear-mounted device, called C-Face, users could express emotions to online collaborators without holding cameras in front of their faces—an especially useful communication tool as much of the world engages in remote work or learning.
“This device is simpler, less obtrusive, and more capable than any existing ear-mounted wearable technologies for tracking facial expressions,” said Cheng Zhang, assistant professor of information science and senior author of “C-Face: Continuously Reconstructing Facial Expressions by Deep Learning Contours of the Face With Ear-Mounted Miniature Cameras.”
The paper will be presented at the Association for Computing Machinery (ACM) Symposium on User Interface Software and Technology (UIST), to be held virtually October 20-23.
“In previous wearable technology aiming to recognize facial expressions, most solutions needed to attach sensors on the face,” said Zhang, director of Cornell’s SciFi Lab, “and, even with so much instrumentation, they could only recognize a limited set of discrete facial expressions.”
With C-Face, avatars in virtual reality environments could express how their users are actually feeling, and instructors could get valuable information about student engagement during online lessons. It could also be used to direct a computer system, such as a music player, using only facial cues.
Because it works by detecting muscle movement, C-Face can capture facial expressions even when users are wearing masks, Zhang said.
The device consists of two miniature RGB cameras—digital cameras that capture red, green, and bands of light—positioned below each ear with headphones or earphones. The cameras record changes in facial contours caused when facial muscles move.
“The most exciting finding is that facial contours are highly informative of facial expressions,” the researchers wrote. “When we perform a facial expression, our facial muscles stretch and contract. They push and pull the skin and affect the tension of nearby facial muscles. This effect causes the outline of the cheeks (contours) to alter from the point of view of the ear.”
Once the images are captured, they’re reconstructed using computer vision and a deep-learning model. Since the raw data is in 2D, a convolutional neural network—a kind of artificial intelligence model that is good at classifying, detecting and retrieving images— helps reconstruct the contours into expressions.
The model translates the images of cheeks to 42 facial feature points, or landmarks, representing the shapes and positions of the mouth, eyes, and eyebrows, since those features are the most affected by changes in expression.
Because of restrictions caused by the COVID-19 pandemic, the researchers could test the device on only nine participants, including two of the study’s authors. They compared its performance with a state-of-art computer vision library, which extracts facial landmarks the image of full face captured by frontal cameras. The average error of the reconstructed landmarks was under 0.8 mm.
These reconstructed facial expressions represented by 42 feature points can also be translated to eight emojis, including “natural,” “angry” and “kissy-face,” as well as eight silent speech commands designed to control a music device, such as “play,” “next song,” and “volume up.”
Among the nine participants, they found that emoji recognition was more than 88% accurate, and silent speech was nearly 85% accurate.
The ability to direct devices using facial expressions could be useful for working in libraries or other shared workspaces, for example, where people might not want to disturb others by speaking out loud. Translating expressions into emojis could help those in virtual reality collaborations communicate more seamlessly, said Francois Guimbretière, professor of information science and a co-author of the C-Face paper.
“Having a virtual-reality headset allows your collaborators to move around and show you the spaces where they are, but it’s very difficult in that situation to capture their faces,” Guimbretière said. “What is very exciting about C-Face is that it gives you the opportunity to wear a VR set, and also to be able to translate your emotions directly to others.”
One limitation to C-Face is the earphones’ limited battery capacity, Zhang said. As its next step, the team plans to work on a sensing technology that uses less power.
In addition to Zhang and Guimbretière, the paper’s co-authors are: first author Tuchao Chen, a visiting student from Peking University; master’s students Benjamin Steeper ’19 and Songyun Tao; and Kinan Alsheikh ’21. The research was supported by the Department of Information Science.
Original Paper: Chen T, Steeper B, Alsheikh K, Tao S, Guimbretiere F, Zhang C. C-Face: Continuously reconstructing facial expressions by deep learning contours of the face with ear-mounted miniature cameras. Paper presented at: The ACM Symposium on User Interface Software and Technology (UIST); October 20-23, 2020; Virtual (previously Minneapolis, MN).
